شیر دو تکه

The valve is used in a variety of industries because of its design and stainless steel makeup. This male by female stainless steel 316 ball valve is perfect for various water, oil, and gas applications. • Two-Piece Investment cast body S.S. 316 • Working Pressure 1,000 PSI (WOG) • Minimal pressure drop due to large full size ports • Suitable for full range of liquids and gas • Temperature range : -40 to 400 degree Fahrenheit • Low operation torque • 100% individually tested • Blowout-proof stem • FxM NPT Threaded ends to ANSI B1.20.1 • Heavy duty locking handles with blue vinyl insulator

شیر سه تکه

Pressure: 1000 PSI Suitable Mediums: WOG (Water,Oil and Gas etc...) Temperature: Rated from -25 up to 356 degrees (Fahrenheit) Port: Full Bore Ball Valve (Full Port, ID of pipe remains constant) Handle Stem: The stem holding the handle is designed to be blow-out proof Locking Device: Locking Handle Device, can be locked in the open or closed position (Can be removed) Threads: Female NPT Thread on inlet/outlet (National Pipe Thread) Dimention Standards: ASME B1.20.1 BS21 DIN 299/259,ISO228-1, JIS B 0203, ISO7/1 Casting: Investment Cast Cast Approved: According to AD2000-WO Inspection Test: According to API598, EN12266 Design and manufacture: CE0035 Approved (PED97/23/EC) The three piece ball valve has two body joints which means the body is made out of of three pieces, giving rise to the name “three piece. This 3 piece body design allows a larger ball to be installed at the time of manufacture, making this a full bore ball valve (Full port) . Full port means that the bore has the same inside diameter as the piping. This means is that pressure drop is kept to a minumum and flow rate is unaffected. The flow rate can be regulated by partially opening or closing the valve, refered to as throttling. Being threaded they are quick to install to and easy to use. Their best feature is that they are the easiest ball valve to clean and service and this can be done without removeing the threaded ends from the pipe.

شیر توپی فلنج دار

ANSI 4-Bolt Flanged Ends, 2-Piece 316 Stainless Steel Body, 316SS trim, Full-Port, Class 150 (150#), Teflon Seals and Seats. Square stem, full ISO5211 mounting pad.

زانو دنده 90 درجه استنلس ستیل کلاس 150

شیر یک تکه استنلس استیل

با فشار کاری استاندارد

شیر دیافراگمی استیل کلمپی دارویی

شیر دیافراگم استنلس استیل کلمپی دارویی 316L,

شیر فلوتر استنلس استیل 304

شیر فلوتر استنلس استیل 304،316 شیر شناور استنلس استیل

سردنده کلمپی استنلس استنلس استیل 316L

clamped nipple 316L
